Tuesday, May 25, 2010

Colour Basics

Electromagnetic Spectrum










Visible Light
                                                                              400 nanometres                        550 nanometres      700 nanometers


The visible portion of the electromagnetic spectrum extends from about 400nm (violet light) to about 700nm (red light) with our eyes having peak sensitivity at about 550nm (green light).




Colour In Image Files

The remainder of this document has been sourced from the Adobe Photoshop CS3 Help Files.
Understanding Colour
Knowing how colors are created and how they relate to each other lets you work more effectively in Photoshop. Instead of achieving an effect by accident, you’ll produce consistent results thanks to an understanding of basic color theory.
Primary colors
Additive primaries are the three colors of light (red, green, and blue) that produce all the colors in the visible spectrum when added together in different combinations. Adding equal parts of red, blue, and green light produces white. The complete absence of red, blue, and green light results in black. Computer monitors are devices that use the additive primaries to create color.








Additive colors  (RGB)
R. Red G. Green B. Blue

Subtractive primaries are pigments, which create a spectrum of colors in different combinations. Unlike monitors, printers use subtractive primaries (cyan, magenta, yellow, and black pigments) to produce colors through subtractive mixing. The term “subtractive” is used because the primary colors are pure until you begin mixing them together, resulting in colors that are less pure versions of the primaries. For example, orange is created through the subtractive mixing of magenta and yellow together.







Subtractive colors (CMYK)
C. Cyan
M. Magenta
Y. Yellow
K. Black




The color wheel
If you’re new to adjusting color components, it helps to keep a standard color wheel diagram on hand when you work on color balance. You can use the color wheel to predict how a change in one color component affects other colors and also how changes translate between RGB and CMYK color models.








Color wheel
R. Red
Y. Yellow
G. Green
C. Cyan
B. Blue
M. Magenta

For example, you can decrease the amount of any color in an image by increasing the amount of its opposite on the color wheel—and vice versa. Colors that lie opposite each other on the standard color wheel are known as complementary colors. Similarly, you can increase and decrease a color by adjusting the two adjacent colors on the wheel, or even by adjusting the two colors adjacent to its opposite.
In a CMYK image, you can decrease magenta either by decreasing the amount of magenta or by increasing its complement, which is green (the color on the opposite side of the color wheel from magenta). In an RGB image, you can decrease magenta by removing red and blue or by adding green. All of these adjustments result in an overall color balance containing less magenta.




Colour Models, Spaces and Modes
A color model describes the colors we see and work with in digital images. Each color model, such as RGB, CMYK, or HSB, represents a different method (usually numeric) for describing color.
A color space is a variant of a color model and has a specific gamut (range) of colors. For example, within the RGB color model are a number of color spaces: Adobe RGB, sRGB, ProPhoto RGB, and so on.
Each device, like your monitor or printer, has its own color space and can only reproduce colors in its gamut. When an image moves from one device to another, image colors may change because each device interprets the RGB or CMYK values according to its own color space. You can use color management when moving images to ensure that most colors are the same or similar enough so they appear consistent.
In Photoshop, a document’s color mode determines which color method is used to display and print the image you’re working on. Photoshop bases its color modes on the color models that are useful for images used in publishing. You can choose from RGB (Red, Green, Blue), CMYK (Cyan, Magenta, Yellow, Black), Lab Color (based on CIE L* a* b*), and Grayscale. Photoshop also includes modes for specialized color output such as Indexed Color and Duotone. Color modes determine the number of colors, the number of channels, and the file size of an image. Choosing a color mode also determines which tools and file formats are available.
When you work with the colors in an image, you are adjusting numerical values in the file. It’s easy to think of a number as a color, but these numerical values are not absolute colors in themselves—they only have a color meaning within the color space of the device that is producing the color.

Adjusting Color Hue, Saturation, and Brightness
Based on the human perception of color, the HSB model describes three fundamental characteristics of color:
Hue Color reflected from or transmitted through an object. It is measured as a location on the standard color wheel, expressed as a degree between 0° and 360°. In common use, hue is identified by the name of the color, such as red, orange, or green.

Saturation Strength or purity of the color (sometimes called chroma). Saturation represents the amount of gray in proportion to the hue, measured as a percentage from 0% (gray) to 100% (fully saturated). On the standard color wheel, saturation increases from the center to the edge.

Brightness Relative lightness or darkness of the color, usually measured as a percentage from 0% (black) to 100% (white).







HSB color model
H. Hue S. Saturation B. Brightness




Colour Modes
Following are some of the major colour modes used :-


  • Bitmap Mode
  • Grayscale mode
  • RGB Color Mode
  • CMYK Color Mode

  • Indexed Color Mode
  • Lab Color Mode
  • Duotone Mode
  • Multichannel Mode

Bitmap Mode
Bitmap mode uses one of two color values (black or white) to represent the pixels in an image. Images in Bitmap mode are called bitmapped 1bit images because they have a bit depth of 1.
Greyscale Mode
Grayscale mode uses different shades of gray in an image. In 8bit images, there can be up to 256 shades of gray. Every pixel of a grayscale image has a brightness value ranging from 0 (black) to 255 (white). In 16 and 32bit images, the number of shades in an image is much greater than in 8bit images.
Grayscale values can also be measured as percentages of black ink coverage (0% is equal to white, 100% to black).
Grayscale mode uses the range defined by the working space setting that you specify in the Color Settings dialog box.
RGB Colour Mode
Photoshop RGB Color mode uses the RGB model, assigning an intensity value to each pixel. In 8bits-per-channel images, the intensity values range from 0 (black) to 255 (white) for each of the RGB (red, green, blue) components in a color image. For example, a bright red color might have an R value of 246, a G value of 20, and a B value of 50. When the values of all three components are equal, the result is a shade of neutral gray. When the values of all components are 255, the result is pure white; when the values are 0, pure black.
RGB images use three colors, or channels, to reproduce colors on-screen. In 8bits-per-channel images, the three channels translate to 24 (8 bits x 3 channels) bits of color information per pixel. With 24bit images, the three channels can reproduce up to 16.7 million colors per pixel. With 48bit (16bits-per-channel) and 96bit (32bits-per-channel) images, even more colors can be reproduced per pixel. In addition to being the default mode for new Photoshop images, the RGB model is used by computer monitors to display colors. This means that when working in color modes other than RGB, such as CMYK, Photoshop interpolates the CMYK image to RGB for display on-screen.
Although RGB is a standard color model, the exact range of colors represented can vary, depending on the application or display device. The RGB Color mode in Photoshop varies according to the working space setting that you specify in the Color Settings dialog box.
CMYK Colour Mode
In the CMYK mode, each pixel is assigned a percentage value for each of the process inks. The lightest (highlight) colors are assigned small percentages of process ink colors; the darker (shadow) colors higher percentages. For example, a bright red might contain 2% cyan, 93% magenta, 90% yellow, and 0% black. In CMYK images, pure white is generated when all four components have values of 0%.
Use the CMYK mode when preparing an image to be printed using process colors. Converting an RGB image into CMYK creates a color separation. If you start with an RGB image, it’s best to edit first in RGB and then convert to CMYK at the end of your process. In RGB mode, you can use the Proof Setup commands to simulate the effects of a CMYK conversion without changing the actual image data. You can also use CMYK mode to work directly with CMYK images scanned or imported from high-end systems.
Although CMYK is a standard color model, the exact range of colors represented can vary, depending on the press and printing conditions. The CMYK Color mode in Photoshop varies according to the working space setting that you specify in the Color Settings dialog box.

Indexed Colour Mode
Indexed Color mode produces 8bit image files with up to 256 colors. When converting to indexed color, Photoshop builds a color lookup table (CLUT), which stores and indexes the colors in the image. If a color in the original image does not appear in the table, the program chooses the closest one or uses dithering to simulate the color using available colors.
Although its palette of colors is limited, indexed color can reduce file size yet maintain the visual quality needed for multimedia presentations, web pages, and the like. Limited editing is available in this mode. For extensive editing, you should convert temporarily to RGB mode. Indexed color files can be saved in Photoshop, BMP, DICOM, GIF, Photoshop EPS, Large Document Format (PSB), PCX, Photoshop PDF, Photoshop Raw, Photoshop 2.0, PICT, PNG, Targa, or TIFF formats.
Lab Colour Mode
The CIE L*a*b* color model (Lab) is based on the human perception of color. The numeric values in Lab describe all the colors that a person with normal vision sees. Because Lab describes how a color looks rather than how much of a particular colorant is needed for a device (such as a monitor, desktop printer, or digital camera) to produce colors, Lab is considered to be a device-independent color model. Color management systems use Lab as a color reference to predictably transform a color from one color space to another color space.
The Lab Color mode has a lightness component (L) that can range from 0 to 100. In the Adobe Color Picker and Color palette, the a component (green-red axis) and the b component (blue-yellow axis) can range from +127 to –128.
Lab images can be saved in Photoshop, Photoshop EPS, Large Document Format (PSB), Photoshop PDF, Photoshop Raw, TIFF, Photoshop DCS 1.0, or Photoshop DCS 2.0 formats. You can save 48bit (16bits-per-channel) Lab images in Photoshop, Large Document Format (PSB), Photoshop PDF, Photoshop Raw, or TIFF formats.
Note: The DCS 1.0 and DCS 2.0 formats convert the file to CMYK when opened.

Duotone Mode
Duotone mode creates monotone, duotone (two-color), tritone (three-color), and quadtone (four-color) grayscale images using one to four custom inks.
Multichannel Mode
Multichannel mode images contain 256 levels of gray in each channel and are useful for specialized printing. Multichannel mode images can be saved in Photoshop, Large Document Format (PSB), Photoshop 2.0, Photoshop Raw, or Photoshop DCS 2.0 formats.
These guidelines apply when converting images to Multichannel mode:
        Color channels in the original image become spot color channels in the converted image.
        Converting a CMYK image to Multichannel mode creates cyan, magenta, yellow, and black spot channels.
        Converting an RGB image to Multichannel mode creates cyan, magenta, and yellow spot channels.
        Deleting a channel from an RGB, CMYK, or Lab image automatically converts the image to Multichannel mode.
        To export a multichannel image, save it in Photoshop DCS 2.0 format.


Bit Depth
Bit depth specifies how much color information is available for each pixel in an image. The more bits of information per pixel, the more available colors and more accurate color representation.
For example, an image with a bit depth of 1 has pixels with two possible values: black and white. An image with a bit depth of 8 has 28, or 256, possible values. Grayscale mode images with a bit depth of 8 have 256 possible gray values.
RGB images are made of three color channels. An 8 bit per pixel RGB image has 256 possible values for each channel, which means it has over 16 million possible color values. RGB images with 8 bits per channel (bpc) are sometimes called 24 bit images (8 bits x 3 channels = 24 bits of data for each pixel).
In addition to 8 bpc images, Photoshop can also work with images that contain 16 bpc or 32 bpc. Images with 32 bpc are also known as high dynamic range (HDR) images.

Sunday, May 16, 2010

EXERCISE 8a




Imaging 1

f


Exercise 8a – Layers - Introduction
Name



§       This is a formative assessment instrument
§       You must be rated ‘Competent’ in this assessment item.

Learning Outcomes
Learning Outcome 5 - Identify and explain a range of digital imaging concepts such as colour mode, colour space and bit depth as well as demonstrate typical fundamental digital image enhancement techniques.
Learning Outcome 6 - Identify digital image workflow patterns and create a simple file management methodology that conforms to established industry norms.

Tasks
1)     Copy the ‘Lesson 9’ folder from the server and place it on the desktop. (Remember to delete this folder when you have completed this exercise).
2)     Start Photoshop CS4 and open the document ‘Image-1.jpg’
3)     Display the Layers palette. Note that only one layer (the Background’ layer) is present.
4)     Click on the ‘Create a new layer’ button at the bottom of the Layers palette. A new empty layer is created above the Background layer, and automatically becomes the new active layer.
5)     Change the name of this layer to Drawing.
a)     Use the brush tool to draw on the new layer. Experiment with different brush settings and colours. See the Brushes palette for more preset brushes.
b)     Use the eraser tool to erase some of your drawing.
(Note : Other drawing tools are outlined below if you want to explore at your leisure. For now we just want a layer with something on it.)
6)     Open the document ‘Image-2.jpg’
7)     Drag the Background layer from the Image-2 Layers palette and drop it onto the Image-1 image window. Note that Image-1 now has two layers.
8)     Change the name of the new layer from Layer 1 to ‘Plane’.
9)     Open ‘Image-3.jpg’.
10)   Use the Move tool to drag the image of the boat directly from its image window onto Image-1. Note you now have three layers.
11)   Change the name of this layer to ‘Ship’.
12)   Select the Move tool and ensure the ‘Auto Select’ option is turned off.
13)   Move the image of the ship to a different location. Note you can click anywhere in the image window to do this.
14)   In the Layers palette click on the Plane layer to make it the active layer.
15)   Use the Move tool to drag the Plane layer to a different location. Note – You can use the Arrow keys to move the layer by 1 pixel at a time, or Shift+Arrow to move it 10 pixels.
16)   Turn on the ‘Auto Select’ option for the Move tool. The tool now automatically selects the layer that you click on to move. What happens when you click on the background layer ?


17)   Go to the Layers palette and drag the Ship layer to underneath the Plane layer.
18)   Click on the eye icons to turn the visibility of layers on and off.
19)   Select both the Ship and Plane layers in the Layers palette. (Use the  or Shift keys to select multiple layers).
20)   Click on the Link icon at the bottom of the Layers palette. (Note the link symbols appear in the Layers palette to indicate the linked layers.)
21)   Use the Move tool to move both layers together.
22)   Click on the Link icon again to unlink the layers.
23)   Choose ‘File->Save As . . .’ to save the document as ‘Exercise 8a Intro.psd’. (You will need this for the next exercise).




Some other drawing tools to try. (These are all located together in a block on tool palette) :-
a)     Use the Marquee tool to create a selection, then use the Paint Bucket tool to fill this area with a colour.
b)     Make another selection area and use the Gradient tool to fill this area :-
i)       Select a Gradient pattern from the preset patterns
ii)      Select a gradient type from the type buttons
iii)     Click and drag on the image to define the size of the gradient.
c)     Burn and Dodge tools.
d)     Pencil tool
e)     Colour replacement tool
